- Tractor side connection outer diameter: 1-3/8

- Number of connecting splines/grooves on tractor side: 6

- Tractor side locking type: Clamping collar

- Tractor side attachment: Quick release fork

- Outer diameter of machine side connection: 1-3/8

- Number of connection ribs/slots on machine side: 6

- Machine side locking type: Clamping collar

- Machine side fixing: Quick release fork

- Size code: W2400

- Length: 1010 mm

- Power at 540 rpm: 39 kW

- Power at 1000 rpm: 61 kW

- Diameter of the crosshead cover on the tractor side: 32 mm

- Length of the universal joint on the tractor side: 76 mm

- Diameter of the crosshead cover on the machine side: 32 mm

- Length of the universal joint on the machine side: 76 mm

- Type of outer tube profile: 2a

- Wall thickness of the outer tube: 4 mm

- Large outer tube outer diameter: 57.5 mm

- Inner tube profile type: 1b

- Inner tube wall thickness: 4.5 mm

- Large inner tube outer diameter: 49 mm

- Protection type: ST25
